which inturn bears against the bearing a. The piece b has a key, /,arhich passes through it and the pipe /. This key bears … Fig. hi.—Thurstons Railroad-Lubricant Testing-machine. against a nut, 0, screwed on the pipe. By turning the nut 0the stress on the journal produced by screwing the rod/canbe thrown on the key /, and the bearing relieved of pressure,without changing the tension on the spring. A counterbalanceabove…
