uired. The tuning-fork with stylus attached,* as in Fig. 277, canbe made to draw a diagram on a revolving cylinder connected See Engine and Boiler Trials, page 234. 576 EXPERIMENTAL ENGINEERING. [§ 4J7« directly to the main shaft of the engine, or the shaft itselfmay be smoked and afterward… … Fig. 279.—Speed-record from Chronograph. curved and at a varying distance apart. From such a diagramthe variation in speed during a single revolution can be deter.mined. 416= Autographic Speed-recorder.—Variations in speedare shown autographically in several instruments by recordingon a strip of…
