Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 69
ding the frame 4Q EXPERIMENTAL ENGINEERING. L§ 29. carrying the pivot and record-wheel until the points c^Fare atthe respective ends of the diagram to be traced, as shown inFig. 11. In the absence of the points U and V the length of thediagram can be obtained by a pair of dividers, and the… … Fig. -Method of Setting the Planimeter for Finding the Mean Ordinate. expressed in the same units as the subdivisions of the record-wheel ; thus if the subdivisions of this wheel are fortieths ofone inch, the result will be the length of the mean ordinate infortieths. This distance, which we term…
