Experimental engineering and manual for testing. For engineers and for students in engineering laboratories (1906)
Carpenter, Rolla C. (Rolla Clinton), 1852-1919 · New York, J. Wiley & Sons; [etc., etc.] · leaf 697
the compression curve on the backstroke can be deducted from the corresponding ordinates of theinertia curve ab, and the included area shaded, thus exhibitingthe modification of the steam-forces by the inertia of thereciprocating parts. By vertical measurement of the shadedportion, the true… … Fig. 295.—Relative Mosuott «f Crank-pin and Piston. of the cross-head and crank-pins with crank on its centre.Then, were it not for the angle of the connecting-rod, thecross-head pin would g. to / when the crank has moved to\d,ppr being equal to oc\ But its true place is at p; thus in the…
