scale, graduated on the upper edge to read in binary fractionsof an inch, and on the lower edge to read in decimals of aninch; this scale can be set at a slight angle with the axis tocorrect for any error in the pitch of the micrometer-screw. … 62 EXPERIMENTAL ENGINEERING. |_§ 43. The graduated disk is doubly graduated ; the right-hand grad-uations corresponding to those on the lower side of the scale.The scale and graduated disk is shown in Fig. 24, and the read-ings corresponding to the positions shown in the figure areO.6822, the…
