A C : AB. Therefore, AB ^ -^ . If from C, determined as before, the angle A C B be laid off equalto yl CB, we have, without calculation, A B = AB. Third Method. Measure a line A D (fig. 35) in an oblique directionfrom the bank, and fix its middle point C From any convenientpoint E in the line of A… … now a point G, that shall be at the same time in the line of CB andof D F, and measure G D. Then the triangles ABC and D G C sreequal, and G D is equal to the required distance A B. As the object of drawing E Fis to obtain a line parallel to A B, thisline may be dispensed with, if by any other…
