ftp $9. 34 MECHANICAL AND ENGINEERING DRAWING Problem 21 (Fig. 69).—To construct a reyular octayon, with a given lenyth of side. Here 360° -f 8 = 45°; and 180° - 45° - 135°. Let AB be thegiven side. Produce it in both directions, and at A and B draw linesAE, BF, of the same length as AB, and making…
