Five hundred and seven mechanical movements (1903)
Brown, Henry T. [from old catalog] · New York, Brown & Seward · leaf 13
for spur gear, 239. sprocket, 254. Stops for winding watches, 212, 213, 214, 215. steering, 490. waved, 165. T Wheels, crown, 26, 219, 237. mangle, 36, 192, 193, 194, 371. Test, friction, 373. paddle, 487, 489. Throstle, spinning, 496. water, 430, 431, 432, 433, 434, 435; 436, 437, 438.… … Mechanical Movements. 1. Illustrates the transmission of power bysimple pulleys and an open belt. In thiscase both of th€ pulleys rotate in the samedirection. 2. Differs from i in the substitution of acrossed belt for the open one. In this casethe direction of rotation of the pulleys is re-versed.…
Mechanical movements
