Flow of water through submerged orifices and short tubes with mouthpieces (1915)

Seely, Fred B., b. 1884 · leaf 36

An illustration from Flow of water through submerged orifices and short tubes with mouthpieces, 1915, leaf 36 — Sketch showing Ar>£an6ement or Apparatus roe.3UBMEZ6ED 5hozt P/pe Lower WITH MOVTHP/ECES.

Hydraulics · Tubes · Hydrodynamics · Theses

Internet Archive · University of Illinois Urbana-Champaign · Public Domain Mark 1.0. Free to use for anything.
