Free-hand drawing : a manual for teachers and students (1904)
Cross, Anson Kent, 1862- · Boston : Ginn · leaf 106
izontal circles of plinth B are repre-sented by inclined ellipses, and so, to givethe right effect, the drawing must be seen ^ ^^ Free-Hand Perspective. from a pomt opposite CV, and about 4^ from the paper. If seen naturally the part B does not form a true SCIENTIFIC PERSPECTIVE AND MODEL DRAWING.… … Fig. 24. Perspective of Circular Plinths. the correct impression of their position. The plinths A and B areof the same size, but it will be noticed that the perspective of Bis wider than that of A. It appears that all depends upon the position of the station-pointfrom which the drawing is to be…
Drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
