nes perpendicular to the wall vanishat point CVvtx AB; therefore, the drawing is unsatisfactory, for all I04 FKEE-HAiXD DKA WING. at the left of AB is outside of both vanishing points, and mostunpleasantly distorted. Fig. 36 shows the same distortion in theleft part of the bureau. The station-point… … Fig. 42. A Satisfactory Representation of One Wall. left of the left vanishing point can be shown. Fig. 42 representsthe wall when thus seen and is a satisfactory drawing. Like anyperspective it requires, however, to produce the same image as theobject, to be seen from the station-point, which is…
