Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 122
Fig. 166 102 Chapter XXXIITHE ARCH THESE arches from the cloister of St. Pauls WithoutGates, at Rome, also illustrate the symmetry ofcylinder, and can be drawn by the same method the the as … Fig. 167 the round window in the last chapter. (See Ch. XXX.) Theyare semi-cylinders and their openings are semicircles (Fig. 169).The semicircles are sketched on a horizontal line (A) which, 103 FREEHAND PERSPECTIVE being above the head in this instance, vanishes downward (Fig.168). The true…
