B. Wrong-, lines J, 2,3 AND 4 ARE TOO &TEE.P. hexagon appears tiltep.Fig. 197 HEXAGONAL PLINTH IN TWO POSITIONS since the vanishing point for one set of lines has not beenactually found. But if these lines have been carefully thoughtout as to direction, the errors will be found… … <mM»g«> ni rm INTERIOR WITH A TILED FLOOR HE plan of this floor is shown in Fig. 199. As drawn inthe example, the foreshortening of the tiles is proportionedto that of parallel surfaces, such as the receding treads or tops of the steps.From the vanish-ing of their edges,we may judgethese…
