Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 159
ust be made in that case. The Cylindrical Picture Plane.— Looking at Fig. 220, we findthat the middle cylinder, whichdoes appear right to the eye,extends equally each side of thecentral direction of seeing, sothat the picture plane is parallelto the apparent breadth of thecylinder. By drawing the… … A. PlanShowing Vi>E OF5PEC-JAL PICTUREPLANES-THEEQUIVALENT OFTHE CylINDRi-CAU PICTURE.PLANE . EYE
Drawing · Perspective
