Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1916)
Norton, Dora Miriam · Brooklyn : The author · leaf 170
shing traceof theroof, —OVPland VP2. The linecontaining thesepoints is the vanishing trace, not only of the roof, hid of the infi-nite plane containing the roof. (It therefore can be drawn as longas needed, being really infinite in length.) So we have only todraw the trace from OVPl to VP2, and… … Perspective OF ABOVE Fig. 238 FREEHAND PERSPECTIVE freehand; but with much greater certainty for knowing that itscenter must fall on the ground in the direction of VPS, and that itcan extend no farther than its meeting with the ray of light, HI.Shadows from a Lamp. — The radiating rays from an…
Drawing · Perspective
