Fig. 108 68 Chapter XXIITHE STUDY AND DRAWING OF A HOUSE M ODEL for the Study. — Make an equilateral triangularprism from cardboard cut as in the diagram (Fig. 110),and place it on the top of two cubes. Put a box or … Fig. 109 books on the table under this model, raising it so that the levelof the eye will fall one-fourth way up on the cubes (Fig. Ill).Place the model about sixteen inches from the eye, and turn itso its long edges will make angles of thirty degrees with the pic-ture plane (Fig. 119). It may now…
