Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes (1910)

Norton, Dora Miriam · Brooklyn : D. M. Norton · leaf 58

An illustration from Freehand perspective and sketching; principles and methods of expression in the pictorial representation of common objects, interiors, buildings and landscapes, 1910, leaf 58 — STRAIGHT-LINE OBJECTS —^-^ - .*--. … in the same direction. And we find that the side margins areforeshortened in length, but not in width; while the front andback margins are foreshortened in width, andthe back one more than the front. This fol-lows the principle of the top of the hollowcylinder in Chapter IV. The Vanishing Point.—…

Drawing
