The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)

Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 146

An illustration from The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .., 1913, leaf 146
eengine, from the bottom of which connection is madewith the bottom of the water jacket. A similar con-nection is made between a point near the top of thejacket and the tank. Once filled, the circulation ofthe water is automatic, the heated water rising in thejacket and flowing from the upper… … TAPPETARMINLETVALVE SPRING INLET VALCHECK GASOLINEFEED CUR Fig. 49.—Sectional View of Cylinder of I. H. C. Engine, ShowingIntegrally Cast Hopper Used in Open Jacket Cooling System. system and the water forced through by positiveaction of the engine. 167. A Good Circulating Pump System.—One plannow…

Internal combustion engines · Farm engines

Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
