The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)
Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 153
FiG. 53.—Single Throw Crankshaft. gine. It must receive the full powder of the engine,must deliver it to the driven machinery, and must bestrong enough to give and to receive the impulse undera twisting strain instead of a straight pull. It should … Fig. 54.—Three Throw Crankshaft, With Counterpoise or Bal-ance Weights. be made of the best mild steel and the crank shouldbe cut out of a mass of metal rather than forged on.The crank-pin should be designed to stand a strainof 400 pounds per square inch of piston area, and the 152 The Gasoline…
Internal combustion engines · Farm engines
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
