The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .. (1913)

Putnam, Xenophon Whiting, 1867- · New York, The Norman W. Henley Pub. Co. · leaf 351

An illustration from The gasoline engine on the farm; a practical, comprehensive treatise on the construction, repair, management and use of this great farm power as applied to all farm machinery and farmer's work indoors and out .., 1913, leaf 351
iter gears. They areused when the direction of the power transmissionmust be changed (Fig. 113). 448. Intermittent Gears.—Intermittent gears areoccasionally introduced into the timing system of agasoline engine, but are not in common use in farmmachinery. Their purpose is to transmit power… … Fig. 115.—Action of Cam Outlined. turning on an axis not at its center, in order thatthey may press more firmly against a near-by leveror spring at one time than another. Often their shapeis such a departure from that of the true wheel thatthey bear little resemblance to it (Fig. 115). 450. Worm…

Internal combustion engines · Farm engines

Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
