The modern gas tractor, its construction, utility, operation and repair; a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction of all parts, their installation and adjustment as well as practical application of tractors in the field (1914)
Pagé, Victor Wilfred, 1885-1947 · New York : Norman W. Henley · leaf 317
al ar-rangement of driving gearing with the various partsseparated in order that their construction may be clearlyascertained is shown at Fig. 137. The power of the Tin: Modern Gas Tractor 319 engine is first directed to the cross shaft shown atA This is mounted on ball bearings of the… … Fig. 138.—Front View of Hackney Gas Tractor Which hasTraction Members at Front End and Single Rear Wheelfor Steering. gear shifting collar operated through a hand leverforming part of the control system. These slidinggears must turn with the cross shaft because they arekept from rotating…
