ompressed rela-tively more at the corners, which lie furthest from the principal axis, than atthe sides. The virtual image of a square seen through a Cx. lens is said tosuffer from positive or pincushion distortion, as in Fig. 248, this being thereversal of the barrel distortion of the real image.… … Fig. 250. Fig. 251. Influence of a Stop.—A diaphragm used with a lens, or combination,diminishes spherical aberration, coma, astigmatism and curvature of field.This accentuates and brings into prominence distortion, so that rectilinearlines of the object near the margin appear curved in the image.…
