Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 187

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 187
§3 FREEHAND AND ORNAMENTAL DRAWING 37 around a pencil in the direction indicated, form a model ofthe device; when set up before you, this will greatly assist inthe representation on the exercise. The length of theellipse from c to d is 42, while its breadth from ^ to / is 34.The interior ellipse is…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
