Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 289

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 289
§5 ELEMENTARY PERSPECTIVE DRAWING 11 laid off from C to a, Fig 7 (a), it can be transferred tothe perspective drawing by projecting a line to / to cutthe vanishing side of the triangle at A. In this samemanner any dimensions can be determined on lines fromC to L and /? by projecting them from the…
