An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 356
and b, c, d, eare laid off 1 inch each to mark the thickness of the ends ofthe case, the width of the bottom of the foot and the widthof the top of the foot, being 1, 2, and 3 inches, respectively.At €, /, g, h, etc. are laid c^ff the widths of the books on thelower shelf—2 inches each. Lines drawn… … PiQ. 54 70 ELEMENTARY PERSPECTIVE DRAWING §5 The corner of the case shown in the elevation a^x hasmarked on it, according to scale, the heights of the lowershelves at k and the thickness and position of the two othershelves at / and ;;z. These are projected across the casetoward F^, and located in…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament
