Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing (1921)

International Correspondence Schools · Scranton, PA : International Textbook Co. · leaf 73

An illustration from Geometrical drawing, projection drawing, freehand and ornamental drawing, wash work and brush drawing, elementary perspective drawing, architectural drawing, 1921, leaf 73
ch other,as at rst, and as the plane of the ellipse approaches thevertex of the cone the ellipse diminishes in size until itreaches its limit in a point. From a point to a circle, then,is the limit of curvature of the ellipse. EXERCISE VProblem 22.—To draw an ellipse, the diametersbeing priven. See…

Architectural drawing · Geometrical drawing · Brush drawing · Perspective · Projection · Decoration and ornament

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
