Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 254
ation of a solid composed of acylinder capped by a portion of a sphere. Draw the true form of thesection made by the plane indicated by the dotted line. (20) SECTION B.In this section you may attempt two questions only. All freehand work employed in this section must be neat andcareful, and its… … Q. 8. *9. Show the geometrical framework on which the given pattern isbased. Show clearly what you consider the unit of repeat, and drawfour repeats, sketching only enough of the pattern to make yourintention plain. (18) *10. Draw the geometrical constructions you think necessary insetting out the…
Geometrical drawing · Design · Drawing
