Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 257
Q. II. EXAMINATION PAPERS. 243 … Q. 12. 244 GEOMETRICAL DRAWING AND DESIGN. II.SECTION A. 1. A drawing made to a scale of ^ of full size has to be re-drawn sothat the dimensions shall be enlarged by one-fifth. Make a scale for thenew drawing, showing feet (up to 3), inches, and (diagonally) eighths ofan inch. Figure the scale…
Geometrical drawing · Design · Drawing
