Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 259
and (2) a line making equal angleswith the two given lines. (16) *6. The diagram shows the plan of a right square pyramid. Draw anelevation. (18) ■^7. The elevation is given of an elbow formed by two pieces ofcylindrical piping. Draw the plan, and also the true form of the inter-section of the… … 246 GEOMETRICAL DRAWING AND DESIGN. ornament should be sketched to show quite plainly what you considerthe unit of repeat. (18) 9. Regular pentagons will not by themselves cover a surface. Drawany form which in combination with regular pentagons would serve thispurpose. Make a diagram of the…
Geometrical drawing · Design · Drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
