scotia moulding is shown. If two lengthsof this moulding are mitred together at right-angles, show the trueform of the cut surface of the mitre. (18) *7. A lamp-shade, in the form of a truncated regular hexagonalpyramid, is made of six pieces of card, of the exact shape and twice thesize shown.… … Q. 8. *9. Draw neatly with instruments the framework or net of thegiven pattern. Show clearly what you intend to be the unit of repeat,and finish not less than four of these so as to show repeats both inwidth and height. (2o) 250 GEOMETRICxVL DRAWING AND DESIGN. *10, Set out, as nearly as you can,…
