Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 264
Q. 9. … EXAMINATION PAPERS. 251 ^11. Redraw the given figure, altering the proportions of the parts sothat the sides of the four corner panels shall be exactly half those of thecentre panel. Make the side of the outside square 3, and the marginsthroughout 02 wide. (16) D 1 I D D 1 1 D Q. II. ^12. Draw an…
Geometrical drawing · Design · Drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
