Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 267
h are eqiiilata-al triangles. Draw the plan, and writedown the angle which the bases make with the vertical plane of pro-jection. (18) 7. A right cone, diameter of base 3I, height 2^, has the plane of itsbase inclined at 45° to the horizontal plane. Draw the plan of the cone,and of its section by a… … Q.8. 254 GEOMETRICAL DRAWING AND DESIGN. cally, and to sketch, freehand, just enough of the pattern to illustrateyour meaning. Show very clearly what you consider to be the unit ofrepeat. (i8) *9. The diagram shows a pattern composedentirely of semicircles. Show two other waysof arranging…
Geometrical drawing · Design · Drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
