Spanton, J. Humphrey (John Humphrey) · London, Macmillan and Co., Limited; New York, The Macmillan Company · leaf 270
Paper IV. Q. 11. 256 GEOMETRICAL DRAWING AND DESIGN. … Paper IV. Q. 12. EXAMINATION PAPERS. 257 SECTION A. *1. The given line AB represents a length of 15 centimetres. Con-struct a scale by which decimetres, centimetres, and millimetres can bemeasured up to 3 decimetres. Figure the scale properly, and show bytwo small marks on it how to take off on it…
Geometrical drawing · Design · Drawing
Internet Archive · Wellesley College Library · Public Domain Mark 1.0. Free to use for anything.
