Gothic architecture in France, England, and Italy (1915)
Jackson, Thomas Graham, Sir, 1835-1924 · Cambridge, University Press · leaf 67
\ ^PF=? --»!* ch. in] THE GOTHIC VAULT 39 advances in front of it with the sweep of the diagonalrib. Consequently the group of ribs shown at theirspringing at A (Fig. 12) after rising a short way comesin front of the jamb C as shown at B, and in an elevationdrawing would hide it. As it is seen from…
Architecture, Gothic
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
