United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 382
ere record is being made,substantially as described. 5. A flexible phonogram disk for use on aflat tablet holder and adapted to receive a locsound record in the form of a spiral groove,substantially as described. In testimony that I claim the foregoing asmy invention I affix my signature in… … (No Model.) 3 Sheets—Sheet 2. C. S. TAINTER. COIN CONTROLLED GRAPHOPHONE. No. 506.348. Patented Oct. 10, 1893.
Phonograph · Patents
