[Graphophone patents] (1878)
United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 706
![An illustration from [Graphophone patents], 1878, leaf 706](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten03unit-706-0.webp)
No. 654,018. Patented July 17, 1900. 0. E. PAYNE. GRAPHOPHONE DRIVE IVIECHANISM. (Application filed June 14, 1899.) (No Model.) … WITNESSED im/ENTOR ATTORNEY'^. THE NORRlS PETEflS CO. PMOTaLfTMO.. WASHINGTON, (Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
