[Graphophone patents] (1878)
United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 92
![An illustration from [Graphophone patents], 1878, leaf 92](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten19unit-92-0.webp)
H. A. MYERS. SOUND BOX. APPLICATION FILED JULY 22,1915. Patented July-24, 1917. 1,234,198. … 'A ATTORNEYPhonograph · Patents
Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
