United States. Patent Office · Washington, D.C., Govt. Print. Off. · leaf 835
1,264,588. C. E. WOODS & F. C. HINCKLEY. START AND STOP MECHANISM FOR TALKING MACHINES.APPLICATION FILED OCT. 15, 1913. RENEWED MAR. 10, 1916. Patented Apr. 30,1918. 3 SHEETS-SHEET 3.
Phonograph · Patents
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Graphophone patents], 1878, leaf 835](https://img.insideoutlibrary.com/img/1024/ia-graphophonepaten20unit-835-382.webp)
