Jacquard machine; analyzed & explained the preparation of Jacquard cards & practical hints to learners of Jacquard designing (1893)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Posselt · leaf 71
62 of the top of a shed. This figure is designed to show the passage of the warp-thread through mail No. 3 of leash and harness No. 3, in Fig. LXIX. … Fig. LXXIII. and harness No, 6, in Fig. LXIX. Fig. LXXIV. is a side view of a thread forming the upper part of a shed where mail and harness have been raised the same as in Fig. LXIX., the warp-thread passing through mail No. 1 1 of leash, a", and harness No. 3. Fig. LXXV. illustrates mail not…
Jacquard weaving
Internet Archive · Getty Research Institute · Public domain (published before 1931). Free to use for anything.
