Christophori Scheiner, e Societate Iesu Germano-Sueui, Pantographice, seu, Ars delineandi res quaslibet per parallelogrammum lineare seu cauum, mechanicum, mobile : libellis duobus explicata & demonstrationibus geometricis illustrata, quorum prior epipedographicen, siue planorum, posterior stereographicen, seu solidorum aspectabilium viuam imitationem atque proiectionem edocet (1631)

Scheiner, Christoph, 1575-1650 · Romae : Ex typographia Ludouici Grignani · leaf 104

An illustration from Christophori Scheiner, e Societate Iesu Germano-Sueui, Pantographice, seu, Ars delineandi res quaslibet per parallelogrammum lineare seu cauum, mechanicum, mobile : libellis duobus explicata & demonstrationibus geometricis illustrata, quorum prior epipedographicen, siue planorum, posterior stereographicen, seu solidorum aspectabilium viuam imitationem atque proiectionem edocet, 1631, leaf 104
8$ PANTOGRAPHICES LIBELLVS SECVNDVS , SVMMARIVM- … Atque fecretiori quodam artificio procedit *, nam res afptBabiles quafuis , fiue piBas feu fi fias \ feu planas feu affieras s fiue planis, feu flexuofis fuperficitbus tnhdirentes s fiue prope feu procul pofit as j fine Hjnas feu piares, continuas fiue di fretas, qua (fi qualefeunque ea demum fint…
