Audsley, W. (William), 1833-1907, Audsley, George Ashdown, 1838-1925 · London ; Glasgow ; Edinburgh : William Mackenzie · leaf 497
t the plane of the picture, being joined, will form the perspectiverepresentation of the square. The operation just mentioned may be said to be of novery great use in drawing perspective, as a transparent plane cannot always be heldbefore an object, for perspectives are made of houses, bridges,… … LINEAR PERSPECTIVE. 5 be had to other means. The point, h, in the ground plane, directly under the eye, isthe point to which the lines are drawn from the object; we have drawn two in thediagram, as more would only have caused confusion: and from the points, a b, wherethey meet the section line, we…
Architecture, Domestic · Architecture, Gothic
