The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 143
DETAILS OF DOOR AND WINDOW.Plate XXVII. This plate will be understood by measurement, and reference to thefigures. Fig. 1. a, stud ; 6, window weight; c, section of window sash ; d,architrave ; e, plastering ; /, sheathing. Fig. 2, is a section of an inside door and its finish ; a, the architrave…
Carpentry · Architecture
