The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 181

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 181
No. 53, as above, represents a plan for a dairy-house, the roof of whichshould be of a high conical form, or span roof, rising from the centre, andprojecting downwards broadly over the sides, to shade the body of the house.(A) represents the milk-room, with broad shelves around the sides, and inthe…

Carpentry · Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
