The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 185

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 185
PLT XXXVIi. DETAILS.Plate XXXVII. Fig, 1. — Column of the portico in front. A, bracketed capital; B, asection of the column ; C, base. Figs. 2 and 3, are two examples of hoods for outside finishing of win-dows. (See elevation.) 91 92 No. 54. MODEL OF A COMPLETE DAIRY. … The above front elevation represents a view of a complete dairy, whichmay form a part of the farmers house, or be distinct from it. No. 55.
