The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 193

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 193
INSIDE DOOR. Plate XXXIX. This plate shows an elevation of an inside door and finish, showingsection through the centre. 95 96 No. 58. … The above is a partial view of a beautiful cottage built for Wm. B. Lang,Esq., on the Highlands in Roxbury. No. 59.

Carpentry · Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
