The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 197

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 197
PLAN OF A GRECIAN HOUSE. Plate XL. This plate represents a ground plan of a house in the Grecian style.We consider this kind of house very economical, both in respect to ex-pense and convenience. By an examination of the plate it will be understood, as the sizes are marked, &c. 13 97 98 iVb.62. … Nos. 61, 62, 63, 64, 65, 66, 67, exhibit seven designs for base, and archi-trave mouldings, full size, for practice
