The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 211

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 211
ANTA AND ENTABLATURE. Plate XLIV. Here we have represented an anta and entablature suitable for thishouse. It is figured in minutes for the sake of convenience ; and drawnto a scale of one inch to a foot. The dark part on the left hand shows a section, or form, of all themembers, &c. 106 No. 71.

Carpentry · Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
