The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)

Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 63

An illustration from The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building, 1854, leaf 63
DORIC TEMPLE.Plate VII. On this plate is exhibited an elevation of a Grecian Doric Temple, inorder to give the student a correct idea of the position of all its members.Their names are given on Plate 8. 31 32 No. 1.

Carpentry · Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
