The carpenter's assistant : containing a succinct account of Egyptian, Grecian and Roman architecture. Also, a description of the Tuscan, Doric, Ionic, Corinthian and composite orders; together with specifications, practical rules and tables for carpenters, and a glossary of architectural terms. Embellished with upwards of 200 plates of plans, elevations, details, and practical stair-building (1854)
Brown, William, architect, Joy, Lewis E · Boston : Published by Edward Livermore · leaf 97
DETAILS OF FRONTISPIECE. Plate XV. This plate gives the details of the Frontispiece, (Plate 14,) one halftheir real size. They will be readily understood by inspection of thePlate. Fig. 1, cornice. Fig. 2, capital. Fig. 3, the base. Fig. 4,lintel. 47 48 No. 16. … CONSTRUCTING A COTTAGE PRIVY, IN CONNECTION WITH A CFSS-POOL OR TANK FOR LIQUID MANURE The privy may be either partially or wholly over the tank, which shouldbe closely covered, on a level with the privy floor, by a flag-stone, as shownm Jjig No. 16. In this figure, a represents the seat, which is…
Carpentry · Architecture
