Handbook for carpet measurers, cutters and salesmen : including topics of general interest to the trade with illustrations and diagrams (1905)
Lind, John W. (John Wilhelm), b. 1861 · New York : George Lyndoe · leaf 56
DIAGRAMS 15, 16, AND 17. DIAGRAMS AND MKASUREMEXTS 39 DIAGRAM 18 Chalk line from A to B across swell, bisect andmeasure depth of it to W; measure from each end of this line A and B to wall atstair C and I); measurewidth of hall from wall tobaluster. DIAGRAM 19 Prolong AB to 0; bisectBO with DE;… … DIAGRAM 18. curve draw EE both waysparallel to AC, chalk linefrom G through f to F per-pendicular to Ee, from Mperpendicular to GF, fromS perpendicular to xM,pro-long it to N, from T andI* perpendiculars to NSM.Measure AB, AC, entranceto c, E, F, and e. Aa, ab,DE, offsets at c and F.IT, Px, FG,…
Carpets
Internet Archive · New York Public Library · Public Domain Mark 1.0. Free to use for anything.
